HC5010L Liquid Cooling Energy Storage Container
- 5.01MWh | Liquid Cooled DC Energy Storage
5.01MWh UL 9540A-certified warehouse, -30°C~50°C operation, NEC 2023 compliant.
Product Features
-
High-voltage DC Architecture1500V DC system, 1123.2~1497.6V range, efficiency ≥87%.
-
Advanced Liquid Cooling5.01MWh max. single capacity, 45kW liquid cooling, temperature difference ≤2℃.
-
Triple CertificationsUL 1973/9540A/NFPA 855 certified, explosion venting + dry pipe sprinklers.
-
Smart O&MOTA updates & self-diagnosis, O&M efficiency +40%.
Technical Parameter
Battery
| Battery Type： | LiFePO4 |
|---|---|
| Battery Cell： | 3.2V/314Ah |
| Battery Pack Configuration： | 1P104S |
| Battery Pack Quantity： | 4 Packs/Cluster |
| Battery Cluster Quantity： | 12 Clusters |
|---|---|
| Rated Current： | 157A*12 |
| Voltage Range： | 1123.2~1497.6V |
| Rated Capacity： | 5015.96kWh |
System
| Weight： | ≤44T |
|---|---|
| Dimensions (W/D/H)： | 6058×2438×2896mm |
| Maximum Efficiency： | ≥87% |
| Temperature： | -30℃～50℃ |
| Humidity： | ≤100%RH（Non-Condensation） |
| Protection Level： | IP54 |
| Anti-corrosion Rating： | C4 |
| Cooling Method： | Liquid Cooling |
| Noise： | ≤75dB |
| Altitude： | ≤4000m |
|---|---|
| Display： | HMI |
| Fire Protection： | Dry pipes with sprinklers, Aerosol (Optional) |
| Communication： | Ethernet |
| Certification： | UL 1973, UL 9540A, UL 9540, UN 38.3, compliant to NFPA 855, NEC 2023, NFPA 70E, etc. |
| Charge/Discharge Rate： | 0.5CP/0.25CP |
| Depth Of Discharge： | 90% |
| Cycle Life： | ≥6000 Cycles (80% SOH @ Standard) |
